601–426 /17 F70 Series106

This function is only available for the FS variants of the projector.

How to swap channels

Select the Menu/ Image / Advanced / Night Vision.

menu

Toggle the Swap channel function on / off by pressing the OK button on the remote control or the keypad.

Image 7–34

Image menu
