Barco F70-4K4 - 3.7 Mounting the FLDX lens (0.38:1) UST lens with a lens support

55601–426 /17 F70 Series
A B
Image 3–25
A Side view
B Top view
Up projection for any projector:
C D
Image 3–26
C Side view
D Bottom view
3.7 Mounting the FLDX lens (0.38:1) UST lens with
a lens support
How to mount
1. Turn the projector on its side or on its top cover.
2. Place the bottom support plate on the bottom plate of the projector. Make sure that the fixation holes
match the holes in the bottom plate.
Lenses, Handling and features
