601–426 /17 F70 Series126
Image 8–44 Example of the Transport delay menu
5. Enter the value either by the arrow keys (one step at a time) or directly by the numeric keys on the remote
control.
6. Click Apply to confirm the value.
7. Repeat this process for every projector in the setup.
8.5 Blending
8.5.1 Introduction to blend functions
When to use blend functions
When two projectors are used together to make one picture on the screen, the blend function must be
activated. This blend function ensures a seamless transition of the images between the two projectors.
The principle is that the light intensity in the blend zone from each projector will be adjusted individually, so
that the rendering on the screen are perceived as from one projector.
The blend function can be enabled for both pictures over/under, and pictures side by side.
The blend will not be affected by the projector's warp.
Picture frame
Projector 1
Picture frame
Projector 2
Width, Projector 2Width, Projector 1
Overlap / Blend Zone
Image 8–45
The Mask adjustments.
The offset adjustments are used to cut the image on each side. Normally used to hide parts of the picture that
shall not be shown on the screen. An example can be: If the source is a pc, you may want to hide the menu
bar at the bottom of the screen.
Installation menu
