243601–426 /17 F70 Series

F.6 Overview video timings DVI Inputs

Overview

The following standard video formats are available for the projector.

Video timing

(active pixels x active lines)

Vertical refresh rate (Hz)

Available layout modes, other

than standard layout (1 x 1

layout)

640 x 480 60

800 x 600 60

1024 x 768 60

1280 x 720 50

1280 x 720 60

1280 x 800 60

1280 x 960 60

1280 x 1024 60

1400 x 1050 60

1600 x 1200 60

1920 x 1080 24

1920 x 1080 25

1920 x 1080 30

1920 x 1080 50

1920 x 1080 60

1920 x 1200 50

1920 x 1200 60

1920 x 2160 60 2 - column mode

1920 x 2400 60 2 - column mode

2048 x 1080 24

2048 x 1080 25

2048 x 1080 30

2048 x 1080 48

2048 x 1080 50

2048 x 1080 60

2048 x 2160 60 2 - column mode

2560 x 1600 50

2560 x 1600 60

3840 x 2160 24

3840 x 2160 25

3840 x 2160 30

Overview video timings for video interfaces
