601–426 /17 F70 Series62
4.1 Installation process
Installation process
1. Ensure that the installation area meets all the environmental requirements. See “Installation conditions”,
page 62.
2. Decide the mounting configuration. See “Orientation”, page 108
3. Unpack the projector, and confirm that the equipment are present, and in good working order. See “Initial
inspection”, page 63.
4. Mount the projector in the decided orientation. See “Orientation”, page 108, and “Projector safe
attachment points”, page 66.
5. Install the lens. See “Replace a lens”, page 45. In case of installing an UST lens, see “Preparing the FLDX
lens (0.38:1) UST”, page 51 and “Mounting the FLDX lens (0.38:1) UST lens with a lens support”, page 55.
6. Connect the source. See “Getting started”, page 73.
7. Power up the projector. See“Power up the projector”, page 77.
8. Adjust and set up the projector. See “Getting started”, page 73.
Do not hesitate to refer to the user manual to obtain more information concerning the user interface
and supplementary information.
4.2 Installation conditions
Environmental Conditions
Barco projectors are manufactured according to specific design standards, which also include
environmental conditions. Failing to follow the terms and conditions outlined in this chapter can
result in loss of product warranty
The table below summarize the physical environments in which the projector may be safely operated or
stored.
Environment
Ambient operating
temperature
Relative Humidity Storage condition
0 -500m +10 to +45 °C 10 –80% RH –20 to +60 °C, 10 – 90 %
RH
500 -1500m +10 to +40 °C 10 –80% RH –20 to +60 °C, 10 – 90 %
RH
1500 - 3000m +10 to +35°C 10 –80% RH –20 to +60 °C, 10 – 90 %
RH
Maximum Air Flow 471m
3
/hour 10 –80% RH Not Applicable
For PRC (People’s Republic of China).the certified altitude is specified on the product label.
Mains power requirement
Projector Power Requirement
F70 100 –240V. 50 –60 Hz.
To protect operating personnel, the National Electrical Manufacturers Association (NEMA) recommends that
the instrument panel and cabinet be grounded.
In no event shall this projector be operated without an adequate cabinet ground connection.
The AC supply must be installed by a qualified electrician in conformance to local codes. Hardware, wire sizes
and conduit types must comply with local codes.
Physical Installation
