601–426 /17 F70 Series80
The WOL is performed by sending a Magic Packet followed by the projectors MAC address. The MAC
address is found in the Menu / Settings / Communication / LAN. menu. The MAC address is similar to the HW
address that is shown in this menu path.
The LAN cable must be connected when the projector enter the ECO mode, in order to obtain the
Wake on LAN function.
Wake-On-LAN (WOL)
The link speed of the projector network interface in ECO mode is reduced to 10Mbit/s. This is
standard practice in the industry to not waste power. Hence, the network connected with the
projector must support such a low link speed to enable the remote wake up of the projector. This
implies that all peripherals (switchers, routers...) in the network path must support WOL and
configured correctly to support WOL.
5.5 Power modes
General
The table below details the projector power modes.
Mode
Description
Normal Projector is booted up and the light source is on
Ready Projector is booted up but the light source is off
ECO Standby Light source is switched off and projector electronics
are powered down
5.6 Customize projector settings
About
The projector display, behavior and user interface can be adjusted to meet individual requirements.
Options include:Menu/Settings/Themes
• Adjust the OSD menu color
5.7 User interface
5.7.1 On Screen Display (OSD)
About
The projector on screen display (OSD) is the primary user interface (UI). From here, you can review and
adjust all projector and display settings.
The OSD interface uses tabs to display the main menu. Topics are then further sorted and displayed by
function: main (topic) — sub (function) — sub (function).
There are seven main menu tabs: Source, Image, Installation, Profiles, Settings, Test pattern and Status.
The OSD can be disabled by pressing the OSD on/off button.
In order to show the OSD, the OSD On/Off button must be disabled. (White backlight on the button).
When the button have blue illumination, the OSD will not appear, and the display information are
only visible on the LCD Display. Only Critical warnings will be displayed.
Getting started
