Do not use for projection to the left when mounted in a frame.
Image 3–19
Required tools
Allen key 2 mm with long shaft (delivered with the kit)
How to prepare the lens
1. Place the lens on a table. Turn out the 6 screws (1). Use an Allen key with a long shaft so that you do not
damage the screw head. These screws will not be reused.
Note: Always use the correct tool (delivered with the kit) to avoid damage to the screw heads !
