7. ICMP
Detailed timings
@EDID
Color depth
(bpc)
Display Mode
(A, B)
Display M ode
2D / 3D
2048 x 2160 @60Hz (aka
4K@60Hz using A+B span)
8, 10 A+B span 2D + 3D
1920 x 1080 @ 60Hz
8, 10
Single
2D + 3D
Includes N TSC r efresh rates = (Hz*1000)/1001
Notes:
• DisplayMode = Single : is a pplicable t o both Dis playPort A , and DisplayPort B input, se parately.
• DisplayMode = A +B : inputs DisplayPort A and DisplayPort B are combined to 1 large r image; in this case the 2 DisplayPort
links need to be genloc ked ( = synchronous and in phase).
• In a ll cases :
- Color Space = RG B,
- Color Sampling = 4:4:4,
- Scan Type = progressive.
• Both Nvidia and AMD GPU’s will not suppor t color depths of 10 bits/color while in 3D-stereo mode.
• Some Graph ical Cards may not permit 10 bits/color at all video timings, because of bandw idth restrictions.
• DisplayPort A and DisplayPort B autom atically detect:
- Active Pixels, and A ctive Lines
- Vertical Refresh
- 8 bits/color - 10 bits/color
- Frame locked
• Upscaled x2 if smaller than 50% of native DMD size, while maintaining aspect ratio (aka automatic 2K → 4K up-scaling on 4K
projectors)
HDMI specifications
HDMI1.4b, including HD CP1.4
Video-timin gs :
• 1920 x 1080p at 60Hz
• 1280 x 720p at 60Hz
• 640 x 480p at 60Hz
• 800 x 600p at 60Hz
• 1024 x 768p at 60Hz
• 1400 x 1050p at 60Hz
• 1280 x 1024p at 60Hz
• 1024 x 768p at 60Hz
• 1280 x 960p at 60Hz
• 1920 x 1080p at 50Hz
• 1920 x 1080p at 24Hz
• 1920 x 1080p at 25Hz
• 1920 x 1080p at 30Hz
• 1280 x 720p at 50Hz
• 720 x 480p at 60Hz (VIC 2)
• 720 x 480p at 60Hz (VIC 3)
• 720 x 576p at 50Hz
Notes:
• Includes NTSC refresh rate = (Hz*1000)/1001
• Upscaled x2 if smaller than 50% of native DM D size, while maintaining as pect ratio ( aka automatic 2K→4K up-scaling on 4 K
projectors)
Audio formats
• LPCM 8-channel (7.1), 16/20/24-bit at 32/44/48/88/96 kHz
Additional features
• YCbCr 4:4:4
• YCbCr 4:2:2
• Deep C olor : 30bpp, 36bpp
R5905963 PROMETHEUS SERIES 09/03/2015
111
