4. Lamp & Lamp House
4.2 Supported xenon lamps f or the S/M Lamp House
Cathode adaptor
A cathode adaptor is re quired to mount the xenon lamp in the La mp House. The cathode adapter has to be mou nted o n the cathode
side of the xenon lamp prior to mounting the lam p in to the Lamp House. The pur pose of the cathode adapter is to position the arc
of the xenon lamp in the middle of the reflec tor inside the Lam p House.
Image 4-4
1 Cathode adapter m anual Lamp House (R865555K)
All lamps and adapters in the table below must be used with the S/M Lamp House (either manual or motorized).
Note that the maximum lamp power the projector delivers depends on the type of projector and the installed
lamp. Prior to install the lam p it’s imp ortant to check w ith the Comm un icator software if the lamp is listed in
the list of supported lamps for this projector.
Supported lamp types and their respective anode/cathode adapters for the S/M Lamp House:
Lamp type
Supplier
Cathode adapter S/M L amp House Barco Order No.
4kW DHP OSRAM XBO
R865555K R9855937
3kW DHP OSRAM XBO
R865555K R9855938
2kW DHP OSRAM XBO
R865555K R9855956
1200W DHP OSRAM XBO
R865555K R9855959
DXL40BAF USHIO
R865555K R9855939
DXL30BAF USHIO
R865555K R9855940
DXL20BAF USHIO
R865555K R9855955
DXL12BAF USHIO
R865555K R9855961
XDC-4000B PHILIPS
R865555K R9856370
WARNING: Always use the correct Cathode adapter for the xenon lamp in the Lamp House. Neglecting this
may result in poor performance of the lamp and damage to the xenon lamp and Lamp House. Some adapters
looks the same, t herefore ch eck the engraved item number u pon the adapter to ensure you use the right
adapter.
40 R5905963 PROMETHEUS SERIES 09/03/2015
