13. Specifications
13.1 Specifications of the P rometheus I
Overview
Digital MicroMirror Device™
3 x 1.38” DC4K dark metal devices
Native reso lution 4,096 x 2,160 pixels
Housing Hermetically sealed DMD and optical assembly
Lamp
2kW included (Xenon)
Up to 4kW poss ible
Compatible with models from all major brands
Light output 7,950 lumens
Screen size Up to 6.5 m (21.3 ft) wide
Brightne ss uniformity 80% at sides, 75% at corne rs
Color u niformity Meets t he DCI/SMPTE 431-1 specs
Native contrast ratio Target: 1,840:1
Min: 1,680:1
Color gamut native red: x = 0.7; y = 0.3
native green: x = 0.2; y = 0.76
native blue: x = 0.145; y = 0.04
Digital Video Inputs
4 x 3Gb/s H D -SDI inputs (max. two single-link HD-SDI, one dual-link H D-SDI or one
quad link 4K )
2 x DVI input
Control I/O
Ethernet
8x GPIO
Serial RS232
Projector diagnostics
Via Communicator postproduction software (included)
Via PC touch pan el (optional)
Via SNM P agent
Prime lenses 1.13 - 1.31
1.31 - 1.86
1.45 - 2.13
1.63 - 2.53
1.95 - 3.26
(equivalent throw ratios for 4K 1.38" DMD)
Power requirements 200-240 V
30 A
50-60 Hz
Dimensions 604(H) x 754(W) x 1129(D) mm
23.78(H) x 29.69(W) x 44.45(D) inch
NB: min. 5 cm of air inlet spac ing req uired at the bottom of projector
Weight
134 kg (295 lbs)
Ambient temperature
35°C / 95°F
Exhaust airflow 350 CFM
Options ACS-2048
3D add-ons
Touch panel
Pedestal
166 R5905963 PROMETHEUS SERIES 09/03/2015
