4. Lamp & Lamp House
4.7 Installation of the xenon lamp in manual S/M Lamp House
WARNING: DO NOT PER MIT UN AUTHORIZED PERSONNE L TO PERFORM OR ATTEMPT ANY PHASE OF
XENON LAM P HA NDLING OR SERVICE. ONLY TRAINED AN D QUALIFIED TECHNICAL SERVICE PERSONNEL
ARE ALLOWED TO HAN DLE THE XEN ON LAMP.
WARNING: This procedure may only be performed by qualified technical service personnel.
CAUTION: Xenon compact arc lamps are highly pressurized. When ignited, the normal operating temperature
of the bulb increases the pressure to a level at which the bulb may explode if not handled in strict accordan ce
to the m anufacturer ’s instructions. The bulb is stable at room temperature, but ma y still explode if dropped or
otherwise mishandled. Whenever the lamp house, containing a xenon lamp, has to be dism antled or when ever
the protective container or clo th has to be removed from the xenon lamp, authorized protective clothing MUST
be wor n!
WARNING: Always wear face protection (full face shield) when handling xenon lamps.
WARNING: Always w ear pro tective clothing (welder’s jacket) when handling xenon lamps.
WARNING: Always w ear clean leather g loves with wrist p rotectors when handling xenon lamps.
This procedure assumes that the anode support assem bly and the side cover are already removed from the
Lamp House due to the removal of the xenon lamp.
Necessary tools
• Torque wrench with a 2,5 mm Allen socket.
• Torque Allen key
• 1,5 mm Allen wrench.
• 22 mm open-end w rench.
• Torque wrench w ith a 22 mm hexagon socket.
• Torque w rench w ith a 5 mm A llen socket.
How to install the xenon lamp in the manua l S/M La mp House?
1. Install the lamp cathode adapter on the cathode of the xenon lamp. Note that som e xenon lamps have a cathode pin with screw
threat (reference 10 imag e 4-27). Screw the adaptor on the anode pin as far as possible. Make sure that there is full contact
between the adapter flat surface and the lamp base. Fasten the s et screw (reference 9 im age 4-27) of the cathode adapter with
a torque of 2.5Nm ( 1.84 lbf*ft). Use a torque wrench with a 5mm Allen socket.
Caution: Ensure that the adaptor is c lean. Periodically clean the adapter. Remove oxide from silver plated adaptor with
standard household metal polish (E.g. Brasso).
Warning: Install the cathode adapter prior to removing the protective container or protective cloth from the xenon lamp.
R5905963 PROMETHEUS SERIES 09/03/2015
53
