7. ICMP
7.5 ICMP reset button and status LED s
ICMP status LEDs and Reset button
LEDs on ICMP front panel give information on the status of the device.
1
2
3
Image 7-7
Status overview PW R/ERROR and RE ADY LEDs:
1 2
PWR/ERROR READY ICMP Status
Off Off Turned off
Red
Off
Board reset
Blinking G reen Off B oot loader
Blinking G reen Blinking O range Operating System start up
Blinking G reen Orange S ecurity Manager - Image Integrity tests
Blinking G reen Blinking Yellow Security M anager - Self Test
Blinking Green
Yellow
Security Mana ger - FPGA s elf-test
Green B linking Orange
Update ongoing
Green B linking Green F IPS o k - Application startup
Green Green Power on & No E rror
Blinking R ed
Off FIPS error
3
Reset button
Button used t o reset ICMP (reference 3 imag e 7-7)
CAUTION: It is not recommended to use the ICMP reset button if conventional means to stop and restart the
ICMP are always available. It is an u ltimate resort in the event of complete b lockage o f interface.
CAUTION: In case the ICM
P is installed in a RGB -laser illuminated cinema projector it is reco mmen ded to put
the lasers in deconditioning state before pressing the reset button and condition them again from the moment
the ICMP is rebooted (after reset). Resetting the ICMP w ith lasers on can create a risk as the proper o peration
of the D MD cooling ca
nnot be guaranteed in this ca se.
R5905963 PROMETHEUS SERIES 09/03/2015 113
