11. Maintenance
11.6 Cooling liquid re fill
WARNING: This procedure may only be performed by qualified technical service personnel.
Order info cooling liquid
B1909086K : bottle of 1 liter cooling liquid.
Necessary parts
Cooling liquid
How to refill
1. Remove the side cover, see "Removal of the side cover", page 139.
2. Open the filler cap by turning it anti clockw ise.
Max
Min
Image 11-6
Cooling liquid refill
3. Fill the reservoir w ith cooling liquid until the level is equal with the Max indication on the reservoir.
4. Close the reservoir again. Turn the filler cap clockwise to close t he reserv o ir.
5. Reinstall the side cov er.
CAUTION: Never fill above M ax level mark !
R5905963 PROMETHEUS SERIES 09/03/2015 155
