3. Physical installation
3.7 Power loop through to the projector e lectronics
This procedure explains how to provide the projector e lectronics with po wer in case no UP S unit is used.
Note that the projector is by default configured for use without UPS. So, the short power link cable is already
installed.
Necessary tools
No tools.
Necessary parts
Short power link cable with p lug type C13/C14
How to loop through the power
1. Plug in the short power cable (1) which was delivered with the projector.
Warning: Always us e the Barc o short power cable w hich is d elivered w ith the projector.
1
2
3
3
Image 3-16
Power loop through connection
2. Secure both plugs o f the short cable with
a fixation spring (2). Handle as follow:
- Squeeze the fixation spring together.
-Slidethefixa t io n spring on the fixation pins (3) while squeezing together and push it against the power p lug.
- Release the fixation spring.
