4. Lamp & Lamp House
4.3 Supported xenon lamps for the XL Lamp House
Anode and cathode lamp adapters are used to position the arc of t he xenon lamp in the middle of the reflector
inside the lamp house. The size of the xen on lamp vary from type to type. Because of that different lamp
adapters are required. Futhermore, some lamp types require an anode adaptation bushing to fi t precisely into
the anode support as sembly. The table below shows for each supported xenon lamp which anode/cathode
adapters have to be used and if an anode adaptation bushing is required.
All lamps and adapters in the table below must be used with the XL Lamp House (either manual or motori
zed).
Note that the maximum lamp power the projector delivers depends on the type of projector and the installed
lamp. Prior to install the lam p it’s imp ortant to check w ith the Comm un icator software if the lamp is listed in
the list of supported lamps for this projector.
Supported lamp types and their respective anode/cathode adapters for the XL Lamp House:
Lamp type /
Supplier
Cathode ad apter Anode adap ter Anode adaptation
bushing
Barco Ord er No.
3000W DHS OFR
OSRAM XBO
R8436061K R859987K
-
R9855950
4500W DHP-OFR
OSRAM XBO
R8436081K R859986K
-
R9855949
6000W DHP-OFR
OSRAM XBO
R8436081K
-
R864132K R98064901
6500W DHP-OFR
OSRAM XBO
R8436081K
-
R864132K R9806860
DXL-30BA
USHIO
R859984K R859985K
-
R9855953
DXL-45BA
USHIO
R8436111K
--
R9855952
DXL-60BA2
USHIO
R8436111K
--
R9806520
DXL-65BA
USHIO
R8436111K
--
R9855951
DXL-65BA2
USHIO
R8436111K
--
R9855962
DXL-70BA
USHIO
R8436111K
--
R9855966
XDC6500B
PHILIPS
R8436081K
-
R864132K R9856380
WARNING: Always use the right adapter(s) for the xenon lamp. N eglecting this may result in poor perfor-
mance of the lamp and damag e to the xen on lamp and Lamp House. Some ad ap ters looks the same, therefore
check the engraved item n um ber upon the adap ter to ensure you uses the right adapter.
R5905963 PROMETHEUS SERIES 09/03/2015 41
