The Instrument Window
The Instrument window gives you
an overview of the selected instru-
ment. You can view detailed instru-
ment data by pressing the D/MENU
Function Key and 1/View Instru-
ment Details. To edit the Instru-
ment data, press the B/Edit Func-
tion Key. More information on edit-
ing instrument data is in chapter
Editing Instrument Data on page
120.
To calibrate the selected instru-
ment, simply press C/Calibrate.
General calibration procedures are
discussed in chapter A Calibration Procedure Using MC5-IS on
page 106. Some calibration examples are available starting from
chapter Examples of Instrument Calibration on page 109.
If a Starting Guide text is written, it appears before the Calibration
Windows are opened. To close the window displaying the note text,
press D/OK.
25.09.2000 10:20
INSTRUMENT
112-TT-003.1
Edit Calibrate MENU
Intake Temperature on Feed 1
Cal. Points
5 ↑↓
Transfer Function
Linear
Method
Simulated
INPUT
0.00 ... 100.00 °C
Sensor Type
Pt100
α
385
Method
Measured
OUTPUT
4.0000 ... 20.0000 mA
Back
