45
Note.
The accuracy of the “Opened @” and “Closed @” values depend
greatly on the change rate of the switch’s input signal.
Hint.
If you use MC5-IS to generate/simulate the switch’s input signal,
you can use ramping to create changing input signals for the switch
under test.
Where to find more information when measuring a switch’s input signal…
Pressure Measurement on page 37
Using External Modules on page 37
Voltage Measurement on page 40
Current Measurement on page 39
Thermocouple Measurement (Temperature) on page 49
RTD Measurement (Temperature) on page 48
Where to find more information when generating a switch’s input signal…
Voltage Generation on page 60
Current Sink on page 58
Thermocouple Simulation on page 65
Ramping on page 69
Measuring
