77
Advanced Utilities
All the subsequent chapters:
• Display Mode Settings on page 77
• Transmitter/Switch Simulation on page 80
• Data Logging on page 83
describe the use of additional features that are available in MC5-
IS. Some of the utilities are firmware options and/or they require
some additional hardware before they can be utilized.
Display Mode Settings
By default, MC5-IS displays all
measurement, generation and
simulation data in engineering
units. In Basic Mode you can also
select some special Display
Modes. To change the Display
Mode, select the Window setup
menu (Commands: D/Menu and
B/Window 2 Setup, if needed) and
choose 3/Display Mode.
All of the available special Display
Modes are described in the sub-
sequent chapters.
Note.
All special Display Modes are reset to Engineering Units Display
Mode if the quantity or port of the window(s) assigned to the spe-
cial Display Mode are changed.
Warning!
Be careful not to mistakenly read a value shown in special Dis-
play Mode as a value shown in Engineering Units. MC5-IS al-
ways displays the true measurement in the window’s lower-
most row (Extra Info row) when a special Display Mode is ac-
tive.
26.04.2002 14:01
P2: INT20C/-1.0 ... 20.7 bar g
E: Current Measurement
gauge
bar1.0357
8.3524 mA
2
Current
1
Pressure
Quantity
[Pressure]
Function/Port
[P2: INT20C]
Unit
[bar]
HART
Setup
Window 2
MENU
Close
Setup
Window 1
Others
Display Mode
[Eng. Units]
Pressure
Type
[gauge]
Zero
Pressure
Module
Eng. Units
Scaling
Percentage
Error
Advanced Utilities
