BEAMEX MC5-IS - Pulse Counting

47
Pulse Counting
The pulse counter terminals are located in the E module.
Required settings Options/description
Quantity Pulses
Funct/Port E: Pls(count)
Also check the Trigg.Edge setting.
MC5-IS compares the external potential
against an adjustable reference voltage
(
Trigger Level, range: -1 … +15 V) when
counting pulses.
The counter may be cleared (zeroed) by selecting
D/Menu, 6/Clear
counter.
Next…
Frequency Measurement on page 46
Switch State Sensing on page 43
Pulse Generation on page 63
Calibration, see Part D.
T / C , L o w V
H A R T
®
1
m e a s / s i n k
V , ,
V ,
1
 

 

,
s i n k
C o m
R , R T D
L o w V
M E A S U R EO U T P U T
E T E
T / C I N T . R J
S E N S O R M E A S U R E & S I M U L A T E
U o : 1 6 V
I o : 2 4 m A
P o : 1 4 5 m W
T / C
W I R E S
O N L Y
4 w m e a s
3 w m e a s
m e a s / s i m
C o m
Measuring
