62
Startup and Basic Operation
Frequency Generation
The frequency generation terminals are located in the ET module.
Required settings Options/description
Quantity Freq.
Funct/Port ET: f(gen)
Also check the Unit and Waveform set-
tings.
MC5-IS generates sine or square wave with
given amplitude and frequency. Sine can
only be generated above 40 Hz. When
generating a square wave, the output DC-
level can be set to symmetric or all posi-
tive.
The amplitude (V
pp
) setting range is:
0.01 V to 5 V both for all positive wave
and for symmetrical wave.
Next…
Pulse Generation on page 63
Frequency Measurement on page 46
Special Generations on page 67
Calibration, see Part D.
T / C , L o w V
H A R T
®
1
m e a s / s i n k
V , ,
V ,
1
,
s i n k
C o m
R , R T D
L o w V
M E A S U R EO U T P U T
E T E
T / C I N T . R J
S E N S O R M E A S U R E & S I M U L A T E
U o : 1 6 V
I o : 2 4 m A
P o : 1 4 5 m W
T / C
W I R E S
O N L Y
4 w m e a s
3 w m e a s
m e a s / s i m
s i n k
V ,
1
,
