BEAMEX MC5-IS - Page 99

91
Connection when measuring/simulating
thermovoltage using a temperature con-
troller and Reference Junction compen-
sation method Entered (also RJ-mode
0°C):
Connection when measuring/simulating
thermovoltage using a compensation
box and Reference Junction compensa-
tion method Entered (also RJ-mode 0°C):
See also…
Internal Reference Junction on page 89
T/C, Low V R, RTD
T/C INT. RJ
SENSOR MEASURE & SIMULATE
T/C
WIRES
ONLY
4 w meas
3 w measmeas/sim
T/C, Low V
T/C
materials
Copper
T
ref
T/C sensor
or a
T/C signal receiver
T/C, Low V R, RTD
T/C INT. RJ
SENSOR MEASURE & SIMULATE
T/C
WIRES
ONLY
4 w meas
3 w measmeas/sim
t
T/C sensor
or a
T/C signal receiver
T/C materials
Copper
T/C, Low V
Connection when measuring/simulating
thermovoltage using a fixed temperature
and Reference Junction compensation
method Entered (also RJ-mode 0°C):
T/C, Low V R, RTD
T/C INT. RJ
SENSOR MEASURE & SIMULATE
T/C
WIRES
ONLY
4 w meas
3 w measmeas/sim
T/C, Low V
Copper
T/C sensor
or a
T/C signal receiver
Temperature
Controller
T
ref
T/C materials
Additional Information
