BODYWORK
4
Unscrew and remove the four screws (9) then remove the fairing cover (3).
Unscrew the two nuts (8) which fix the rearview mirrors (7) and the upper fairing (4) to the support
(2). Repeat the same operations on the opposite side of the bike (refer to the drawing).
Front fairing removal
Unscrew the three fixing screws (10) of both side fairings (11) and widen with care or remove
completely to remove the front fairing.
Slip the front fairing (4) off.
Sub 4-3
