INJECTION - IGNITION
9
Air temperature sensor (engine)
The sensor (3) is positioned under the dashboard support frame and take the external temperature
of the air that is used by the ECU to make eventual calibration corrections.
Ignition coils
Remove the fuel tank.
Undo the nut (1) securing the coil to the cylinder head.
Remove the connector (2) and extract the coils (3) from the spark plugs on both cylinder heads.
Clean the area around the spark plug bores with a compressed air jet before removing the spark
plugs themselves.
Remove the spark plugs, making sure that dirt does not fall into the combustion chambers.
