bimota DB7 - Airbox and Throttle Body Removal

EXHAUST - INTAKE
8
Airbox and throttle body removal
Remove the fuel tank.
Remove the air intake manifolds.
Release the throttle cable.
Disconnect the wiring (27) from the injectors (13). If needed disconnect the wiring (27) from the
main electric wiring.
Loosen the clamps (3) on the intake manifold (1).
Sub 8-11
