ELECTRICAL SYSTEM
10
10.7 - Dashboard
Dashboard removal
Remove the front fairing.
Disconnect the wiring of the dashboard (1)
Unscrew the three screws (2).
Remove the dashboard (3).
NOTES
The dashboard is supplied as spare part in a single component and therefore it is not possible to
order internal replacements.
Sub 10-35
