USE
MAINTENANCE
3
3.4 - MAINTENANCE OPERATIONS
Engine oil level control
The engine oil level visible by the inspection window (1) positioned on the right side of the oil
sump. Wait a few minutes after having switched off the engine in order to stabilize the level.
Check the level with the vehicle in upright position and with warm engine (but switched off).
The level has to remain between the MIN and MAX marks. If the level is low it is necessary to
proceed to top up.
Take off the loading cap (2) and add the appropriate oil, up to the fixed level.
Screw the cap in and mount the removed parts.
Sub 3-8
