TECHNICAL
SPECIFICATIONS
2
Rear wheel
Reference Normal value Limit value
Tire tread min. thickness Max wear point 2 mm
Tyre pressure At cold 2.3 bar
Wheel pivot imperfection In 100 mm 0.2 mm
Wheel rim imperfection radial 0.8 mm 2 mm
axial 0.5 mm 2 mm
Final drive
Type Reference Technical spec
REGINA 135ZRDK-100MG size 5/8” x 5/16”
Links number 99+1 open link
Rear suspension
Reference Technical spec
Model Extreme tech
Progressive dumping, use an rocker
arm between the frame and the shock
low pivot. The mono-shock is rebound
and compression adjustable (low and
high speed) and it’s also spring preload
adjustable.
Mono-shock Stroke 60 mm
Hydraulic brakes standard position: unscrew
the regulators from all close position
(counter clockwise)
High and low speed compression: 10
clicks
High and low speed rebound: 10 clicks
Spring preload 15 mm
Wheel stroke 130 mm
