bimota DB7 - Frame

CONTROLS AND
DEVICES
5
To remove the rear master cylinder (8) is necessary to remove the right engine plate (28).
Unscrew the screws and the nut (29) and remove the right engine plate (28).
Unscrew the fixing screws (7) of the rear brake pump (8) to the right plate engine (28).
Remove the oil reservoir (3) together with its hose (5) from the frame unscrewing the screw (1).
Remove the complete rear brake control.
Sub 5-8
