bimota DB7 - Drive; Drive System; Engine

TECHNICAL
SPECIFICATIONS
2
Engine
Reference Technical specs
Type 4 stroke, 90° L twin
Bore 104 mm
Stroke 64,7 mm
Displacement 1099 cm³
Compression ratio 12,5 ± 0,5 :1
Shaft horsepower (95/1/CE) 113 kW (154 CV) / 9750 min-1
Shaft torque (95/1/CE) 118 Nm (Kgm) / 8000 min-1
Min rpm 1300 ± 50 min-1
Max rpm 10700 rpm
Timing system Toothed belt with double over head camshaft, 4 valves
per cylinder and 8 rocker arms
Lubrication system Forced lubrication by, with oil cooler
Oil pump type Geared
Cooling system Liquid cooling system
Air filter Two filter units
Crankshaft type One-piece
Drive
Reference Technical specs
Clutch Dry multi-plate clutch
Clutch control Hydraulic control
Gearbox 6 speed gear
Primary drive 32/59
Secondary drive 15/38
Gearbox type With constant mesh spur gears, operated by a
lever on the left side of the motorcycle
Drive system
GEAR RATIO
1° 15/37
2° 17/30
3° 20/28
4° 22/26
5° 23/24
6° 24/23
Sub 2-3
