ELECTRICAL SYSTEM
10
Turn signal bulb replacement (USA version only)
In the Europe version in case of malfunctioning it is necessary to replace the whole rear turn signal
or the rear view mirror group (which includes the front turn signal light), as they use LED and not
bulbs.
Front turn signals
Unscrew the screw (1) from the internal part of the rear view mirror and remove the lens (2) paying
attention to the joint (3).
Press the bulb (4) softly and turn it counter-clockwise to remove it.
Replace the bulb (4) and re-insert it in the support. Reassemble the lens (2).
Re-screw the screw (1).
Rear turn signals
To replace the bulbs of the rear turn signals, unscrew the screw (1) and take the lens (2) out from
the signal support.
Press the bulb (3) softly and turn it counter-clockwise to remove it.
Replace the bulb (3) and re-insert it in the bulb support.
Reassemble the lens (2) on the turn signal support.
Re-screw the screw(1).
Sub 10-30
