ELECTRICAL SYSTEM
10
High-beam light bulb replacement
Remove the front fairing covers.
Remove the rubber cover (1).
Push the two fixing springs (2) out.
Remove the burnt light bulb (3) disconnecting the connector (4) and replace it with a new one
reversing the order of removal.
Reassemble the rubber cover.
Reassemble the front fairing cover.
Parking light bulb replacement
The parking light bulb is accessible from the lower part of the front fairing
To renew it pull the light bulb socket (1) out.
Remove the light bulb (2).
Install a new light bulb reversing the order of removal.
