WHEELS-BRAKES-
SUSPENSIONS
6
Front wheel removal
Remove the front brake calipers together with their hoses by unscrewing the screws (12).
Recover the spacers (9).
CAUTION
Not operate the brake lever when the calipers are dismantled. This might cause the expulsion of
the pushing pistons of the brake pads.
Not to damage the brake hose, the pliers unit should not remain attached to cable. Besides be
careful not to twist the brake hose.
Support adequately the motorbike so that the front wheel is raised from the ground.
Loosen the screws (14) of the L.H. leg lower end.
Unscrew the special screw (13) from the front wheel axle.
Sub 6-3
