bimota DB7 - Tail - Seat

BODYWORK
4
4.4 - TAIL – SEAT
Tail removal
Unscrew the screw (1) of the exhaust silencer holder.
On both side of the bike unscrew the screws (2) which tie up the tail (3) to the frame plates.
Slip off the tail (3) towards the direction indicated by the arrow paying attention to disconnect the
rear turn signals cable and the rear lights cable (4).
Sub 4-7
