TECHNICAL
SPECIFICATIONS
2
2.2 - TORQUE SETTINGS
Frame torque settings
Description Size (mm) Torque (Nm) Notes
GENERAL
Screw M4 4 3
Screw M5 5 5-6
Screw M6 6 10-12
Screw M8 8 22-25
Screw M10 10 50
Screw M12 12 85-90
SIDE STAND
Side stand rotation screw M8 20 Loctite 243
Side stand plate to carter locking screw M10x25x1,5 40 Loctite 128455
Locking screw of the small plate side stand switch holder M5x10 6 Loctite 243
Locking screw of the limit switch plate M5x10 5 Loctite 243
Locking screw of the side stand sensor holder M5x8 5 Loctite 243
Side stand base locking screw M4x8 3 Loctite 243
Side stand spring locking screw M8x12 20 Loctite 243
FRONT / REAR SPROCKET - CHAIN
Front sprocket locking nut M25x1 186 Grease
Locking screw of the front sprocket cover M6x12x1 8
Nut + shock-absorber pivot to fixing the rear sprocket to
the sprocket-holder flange
10x1,25 40
Grease under head
Loctite 222
LIGHTING DEVICES
Locking screw of head-light holder to upper fairing M5x12 5 243
Locking screw of head light to holder self-tapping manual
Screw + rear turn light locking nut M6x20 8
Rear light locking nut M6 8
Locking screw of rear light to tail M5x14 5
Locking screw of rear light to small plate (USA) M4x10 3
Screw + locking nut of rear light plate to license plate
holder (USA)
M5x12 5
Screw + locking nut of license plate holder to tail M5x16 5
Locking nut of license plate light M5 4
NOTES
The tightening torque must be applied slowly and gradually using a calibrated torque wrench tool.
In case of screwing with automatic impact wrench, the reference torque must be reduced of 10%.
Sub 2-12
