TECHNICAL
SPECIFICATIONS
2
Description Size (mm) Torque (Nm) Notes
ELECTRICAL SYSTEM
Control Unit locking screw M4x20 3 Loctite 243
Screw + locking nut of the fuse box to the frame M5x10 5
Screw + horn locking nut M6x16 8
Voltage regulator locking screw M6x20 10
Lambda sensor M18x1,5 45
Battery box locking screw M6 10
Battery box fastener locking nut M6 8
Speed sensor locking screw M4x5 3 Loctite 222
FRONT FORK – STEERING HEAD TUBE
Locking screw of the fork small foots M8x40 22 Grease
Locking screw of the fork stems to the steering base M6x25 12 Grease
Locking screw of the fork stems to the steering head M8x22 25 Grease
Locking screw of the steering ledge spacer M6x10 10 Loctite 243
Locking screw of the steering head to the steering pivot M8x22 25 Grease
Special locking screw of the steering head M30x1x13 30 Grease (under head)
Locking ring nut of steering bearings M35x1 30?? Grease
STEERING DAMPER
Locking screw of the steering damper eye to the clamp M6x25 10 Loctite 222
Locking screw of the steering damper clamp to the fork M5x22 5 Loctite 222
Locking screw of the steering damper to the frame M6x25 10 Loctite 243
Locking screw of the nylon collar M4x8 3
REAR SHOCK
Screw + locking nut of the shock to the eccentric cam M12x1,25x98 60 Grease
Screw + locking nut of the shock to the rocking arm M12x1,25 60 Grease
Screw + locking nut of the small connecting rod to swing arm M10 35
Screw + locking nut of the small connecting rod to rocking arm M10 35
Rocking arm pivot / engine plates locking screw M12x1,25x25 60 Grease (under head)
Rocking arm pivot / engine plates ring nut M24x1 50/100 ?????
Locking nut of the engine plates to the rear engine pivot joint M10x1,25 35 Grease
Locking screw of the engine plate to the engine M10x32 40
Grease (under head)
Loctite 243
Swing arm pivot special locking screw M16x1,5x20 55 Grease (under head)
NOTES
The tightening torque must be applied slowly and gradually using a calibrated torque wrench tool.
In case of screwing with automatic impact wrench, the reference torque must be reduced of 10%.
Sub 2-13
