USE
MAINTENANCE
3
Tighten the screw (3), which fix the steering head to the steering pivot, to prescribed torque.
.
Chain tension adjustment
Move the motorcycle to find the position where the upper part of the chain is more tight. Place the
motorcycle on its side stand with the gearbox in neutral (best if you have a central stand).
Place the ruler in the position indicated by the arrow (see the sticker on the swing arm).
Push the chain downwards and tension up until the distance between the swing arm and the chain
pin centre is 58÷60mm.
CAUTION
If the slack is more than 60 mm, the chain may damage the swing arm.
Sub 3-34
