WHEELS-BRAKES-
SUSPENSIONS
6
Fork disassembly
Remove the upper fairing, the front brake calipers, the front fender, the front wheel.
NOTES
Before slipping the forks off measure with a calliper or take note of the marks visible on the fork
from above the steering head. They indicate the unthreading of the fork of the steering head
recommended by Bimota.
Loosen the clamp bolts (16).
Loosen the bolts (17) securing the handlebar clamps to the fork legs.
Sub 6-6
