INJECTION - IGNITION
9
Coolant temperature sensor (dashboard)
The sensor (1) is positioned along the horizontal hose of the coolant circuit, under the throttle body,
and measures the water temperature which is then displayed on the dashboard.
Air temperature (dashboard)
The sensor (2) is positioned under the dashboard support and measures the external air
temperature which is displayed on the dashboard.
Sub 9-9
