ELECTRICAL SYSTEM
10
License plate light bulb replacement
The license plate light bulb is accessible from the back side of the license plate support.
Pull the light bulb socket (1) out.
Remove the license plate light bulb (2).
Install a new light bulb reversing the order of removal.
Lights relay
The lights relay (3) is placed on the right side of motorcycle and is fixed near to the ECU.
To have access to this component is necessary to remove the R.H. side fairing.
The lights relay is managed by the ECU that carry out the “light saving” function.
Sub 10-23
