bimota DB7 - Cooling System; Front Wheel; Front Suspension

TECHNICAL
SPECIFICATIONS
2
Cooling system
Reference Technical spec
Type Liquid cooled, closed circuit type, with double
fan curved radiator and mixing thermostat
Coolant capacity 2.7 ± 0.5 lt
Front wheel
Reference Normal value Limit value
Tire tread min. thickness Max wear point 2 mm
Tyre pressure At cold 2.3 bar
Wheel pivot imperfection In 100 mm 0.2 mm
Wheel rim imperfection radial 0.8 mm 2 mm
axial 0.5 mm 2 mm
Front suspensions
Reference Technical spec
Model Marzocchi Spring preload and
rebound/compression adjustable
upside-down fork
Fork Stem diameter 43 mm
Stem stroke 120 mm
Hydraulic brake
Standard position: unscrew the regulators
from all close position (counter clockwise)
Compression: 1 turn
Rebound: 1,5 turns
Spring preload
Standard position: unscrew the regulators
from all close position (counter clockwise)
7,5 turns
Stem oil capacity
Sub 2-6
