bimota DB7 - Particulars

TECHNICAL
SPECIFICATIONS
2
2.1 - TECHNICAL SPECIFICATIONS
Colors
Code Description Additional description
X 14451 Bimota red Lechler
X 14446 Pearl white Lechler
Particulars
Reference Technical specs
Dimensions Total length 2040 mm
Total width 730 mm
Total height 1105 mm
Wheel base 1430 mm
Handlebar height (from the edge of grip
to the ground)
810 mm
Seat height 810 mm
Dry weight without liquids and battery 172 Kg
Curb weight with full load 300kg
Frame Type Composite structure: steel CrMo4
tubes framework and aluminium
6082 plates
Rake 25°
Steering angle 22°
Trail 100 mm
Front wheel Forged aluminium alloy
Front wheel size MT3.50x17”
Front tyre size 120/70-ZR17
Rear wheel Forged aluminium alloy
Rear wheel size MT6.00x17”
Rear tyre size 190/55-ZR17
Front brake Semi-floating holed dual discs
Rear brake Semi-floating holed disc
Sub 2-2
