bimota DB7 - Air Filters Replacement and Cleaning

USE
MAINTENANCE
3
Air filter replacement and cleaning
Intake air filter
The air filter must be replaced at the intervals described on the "periodic service tab" .
1)Filter box
2)Air Filter
3)Rubber gasket filter support
4)Support sleeve air box
5)Screw
6)Sleeve
7)Air intake pipe
to access to the air filter:
remove the left side fairing (8) as described in the “fairings” sub-chapter.
Sub 3-16
