INJECTION - IGNITION
9
Battery support removal
The battery is placed on the motorcycle left side, under the side fairing.
Remove the L.H. fairing.
Remove the box cover (13) loosening the nuts (7).
Disconnect first the negative pole (22) then the positive one (23).
Remove the battery (12) from its box.
To reassembly the battery perform the same operation in reverse order, taking care to connect first
the positive terminal (23) then the negative one (22).
Sub 9-4
