INJECTION - IGNITION
9
Disconnect the connector (24) from the main wiring, slip the starter contactor (19) off from the two
fixing tongues and remove it.
Slip the fuses box (25) off from the fixing tongue and remove it.
Unscrew the screw (15) and remove the lights relay (26).
Unscrew the two screw (8) (9) and recover the washers. Remove the battery support (11).
Sub 9-5
