bimota DB7 - Hydraulic Brakes; Charging System; Alternator

Sub 2-7
TECHNICAL
SPECIFICATIONS
2
Hydraulic brakes
Reference Normal value Limit value
FRONT
Brake disc Type Dual semi-floating holed
discs
Thickness 5 ± 0.1 4.5 mm (min)
Slide material Steel
Diameter 320 mm
Braking surface 39,6 cm²
Brake caliper Model BREMBO
Type 34-4 pot
Pot diameter 34 mm
Pads material TT2910
Master cylinder Type Radial master cylinder
Master cylinder bore Ø 18 mm
REAR
Brake disc Type Semi-floating holed disc
Thickness 5 ± 0.1 4.5 mm (min)
Slide material Steel
Diameter 220 mm
Braking surface 31.2 cm²
Brake caliper Model BREMBO
Type 32-2 pot
Pot diameter 32 mm
Pads material FERODO I/D 450
Master cylinder type Hydraulic pump
Master cylinder bore Ø 11 mm
Charging system / alternator
Reference Technical spec
Battery Voltage 12 V
Capacity 10 Ah
Type Airtight, maintenance free
Alternator Capacity 12 V – 480 W
