USE
MAINTENANCE
3
Unscrew and remove the 3 fixing screws (5), and release the sleeve holder (4) and sleeve (6) from
the filter box (1) being careful to damage not the rubber gasket.
The intake manifold (7) must not be removed from the sleeve (6).
Remove the air filter (2) from the filter box (1).
Clean the filter (2) using a jet of air compressed, or replace it.
Reinstall the cartridge in the filter box and reassembly all the parts and the removed
structures.
IMPORTANT
An air filter obstructed reduce the air entry, increasing the fuel consumption, reducing the
engine power, encrusting the spark plugs.
Don’t use the motorcycle without the air filter, because the dust may enter into the engine,
damaging it.
In case of use on dusted or wet roads, replace the filter often.
Sub 3-17
