USE
MAINTENANCE
3
Engine oil and filter cartridge replacement
NOTES
This operation must be performed at warm engine (engine off) because the oil in these conditions
is more fluid and its drainage is faster and complete.
Remove fairings.
Remove the drain cap (3) with seal (A) of the engine oil sump and drain the exhausted oil.
CAUTION
Not waste exhausted oil and / or filter cartridges in the environment.
Check that there are no metal particles attached to the magnetic drain cap (3), so re-screw the cup
with its gasket (A)
Tightening to the required torque.
Remove the filter cartridge (4) using an oil filters standard tool.
IMPORTANT
The removed filter can not be reused.
Mount a new cartridge (4) taking care to lubricate the seal with oil engine.
Screw into place and lock with the required torque
NOTES
It is also possible to fill the filter cartridge (4) with engine oil before mounting it.
Sub 3-9
