WHEELS-BRAKES-
SUSPENSIONS
6
Removal of the rear wheel
Lift the rear wheel from the ground using a bike stand that hold the swing arm side supports (1).
Loosen the rear wheel pivot (2).
Remove the rear axis pivot.
Bring forward the wheel and remove the drive chain from the rear sprocket.
Remove the rear wheel.
Installation notes:
To install the rear wheel, reverse the removal procedures.
Adjust the drive chain.
Tighten the rear wheel pivot to the specified torque: 100 Nm.
NOTES
Pay attention to do not damage the brake pads installing the wheels.
After having installed the wheel, operating the brake several times then check that the wheel spins
free.
Check the wheel again if the brake makes contact and if the wheel doesn't spin free.
If you have not used a torque wrench for the installation, contact soon a Bimota dealer to check if
the installation has been correctly done. If the installation is not correct you might have reduction in
the braking performance of the bike.
