WHEELS-BRAKES-
SUSPENSIONS
6
Removal of the rear brake caliper
IMPORTANT
The brake caliper manufacturer advises against any servicing of the internal components of
calipers. Incorrect overhaul of this safety-critical component can endanger rider safety.
An overhaul not correctly done can seriously endanger the pilot safety.
Operations should be limited to renewal of the pads, fasteners and the bleed valve assembly.
For the substitution of the components mentioned above refer to exploded draw at the beginning of
chapter.
Empty the rear brake circuit.
Unscrew and remove the screw (1) that fixes the brake hose (3) to the rear brake caliper and the
relative gaskets (2).
Unscrew the two screws (6) then remove the rear brake caliper (4).
NOTES
For the brake pads replacement operations follow what mentioned in Chapter “USE AND
MAINTENANCE – brake pads wear check-up and replacement.”
Sub 6-23
