USE
MAINTENANCE
3
Rebound hydraulic brake:
Rotate with a screwdriver the adjuster (2), placed on the top of each fork stem, to adjust the
rebound hydraulic brake.
SOFT: rotate the adjuster counter clockwise, towards to SOFT position, in case of light weights,
and driving on normal and plain roads.
HARD: rotate the adjuster clockwise, towards to HARD, for a more severe driving.
Compression hydraulic brake:
Rotate with a screwdriver the adjuster (3), placed on the fork foot, to adjust the compression
hydraulic brake.
SOFT: rotate the adjuster counter clockwise, towards to SOFT position, in case of light weights,
and driving on normal and plain roads.
HARD: rotate the adjuster clockwise, towards to HARD, for a more severe driving.
Sub 3-43
